A70-W365                                                         A70-WG
























          A70-W365 is a compact and elegant LED luminaire for mirrors. The luminaire is   A70-WG is a modern gooseneck luminaire with a powerful LED light source and
          flexible and can be mounted both horizontally and vertically beside the mirror. With   flexible arm. The light source is positioned well inside the lamp head, in order to
          the small size and simple form the A70-W365 suits most projects. Available in three   avoid glare. This makes it possible to focus the concentrated reading light exactly
          colors grey (RAL 9006), White (RAL 9016) or Black (RAL 9005) the diffuser is made   where it is required, without disturbing the surroundings. The gooseneck design
          of impact resistant opal polycarbonate (PC) can be supplied with integrated motion   makes it easy to change the direction of the light. The aluminium lamp head is de-
          sensor. A70-W365 is a versatile solution for private and public projects.  signed to divert heat. The user will not experience any discomfort when handling the
                                                                           luminaire while it is lit. A70-WG is an excellent bedside reading light.




          Light source  LED 600 - 1100 lumen outColour temperature 3000/4000 K,   Light source  LED 300 lumen out
                        CRI Ra 80, MacAdams 3                                            Light source information:
          Ballast       Fixed output (HF), DALI dimmable (10-100%)                       3000/4000 Kelvin, CRI 80,MacAdams 3.
          Material/colour  Housing in die-cast aluminium, painted in polyester powder    Lifetime LED:
                        paint in colour grey (RAL 9006), White (RAL 9016) or Black       Up to 60.000h Ta25.
                        (RAL 9005). Diffuser is in impact resistant opal polycarbonate   For precise technical information please see the data sheet on
                        (PC)                                                             item level. (Use  on right side)
                                                                           Ballast       Integraded dimmable driver (100-1%) with an integrated switch.
          Dimension (mm)  W: 62   L: 368   H: 66
                                                                                         USB-charger for mobile phone and tablet provide 2,5A / 5V.
                                                                           Material/colour  The housing in black (RAL 9005) is made of solid PA (polyam-
                                                                                         ide), gooseneck is produced with solid material and is coated
                                                                                         in black rubber. The head is made in aluminium. Selection of
                                                                                         different decor plates.
                                                                           Dimension (mm)  W: 91   L: 200   H: 110
                                                                                         W: 91   L: 200   H: 151











































         2/18    For detailed information on products, see www.glamox.com
