A20-SQ A20-P166

Design: Formel Industridesign Design: Formel Industridesign

Glamox A20 is a slim and refined family of luminaires with modern shape and pleas- Glamox A20 is a slim and refined family of designer luminaires with modern shape
ant light distribution. A20-SQ is a square surface mounted luminaire with exciting and pleasant light distribution. Our designers have first and foremost developed a
backlight which creates a calm and appealing atmosphere. The luminaire works product that expands the possibility of an overall style throughout the building. A20-
well as both ceiling and wall mounted. A20-SQ with LED is available as 300x300 P166 is a pendant tube shaped luminaire with a pleasant light distribution. Available
and 400x400 mm. The luminaire is supplied with first-class materials in an elegant in several different lengths well suited for different applications and ceiling heights.
and precise finish. The luminaire housing is in die-cast aluminium and with a grey All variants are supplied with an opal satin acrylic diffuser with 166mm in diameter.
polyester powder trim. A20-SQ is delivered with an opal satin acrylic diffuser and A slim and stylish pendant luminaire for direct and indirect lighting.
some variants can be delivered with microwave sensor.

Light source A20-SQ300: LED 1500 lumen out Light source A20-P166 LED 1200 - 8000 lumen outLight source informa-
A20-SQ400: 2500, 3000 & 4000 lumen out tion:3000/4000 Kelvin, CRI 80, MacAdams 3.Lifetime LED:
Light source information:3000/4000 Kelvin, CRI 80, MacAd- Up to 100,000h Ta25.For precise technical information please
ams 3. see the data sheet on item level. (Use
Lifetime LED:Up to 60.000h Ta25. Ballast Electronic ballast (HF) or DALI
Ballast Electronic ballast (HF), analogue dimming (HFDa), digital dim- Material/colour Housing in die-cast aluminium, painted in polyester powder
ming (HFDd) or DALI. paint in colour grey (RAL 9006). Reflector made of anodized
Material/colour Housing in die-cast aluminium, painted in polyester powder aluminium. Opal satin acrylic diffuser
paint in colour grey (RAL 9006). Opal satin acrylic diffuser. Dimension (mm) Ø: 166 H: 400
Dimension (mm) W: 300 L: 300 H: 100 Ø: 166 H: 675
W: 400 L: 400 H: 100 Ø: 166 H: 975
Ø: 166 H: 1275
