A71-SQ A90-P

Design: Hans Bleken Rud, EGGS

A71-SQ is a compact LED luminaire for surface mounting on walls and ceilings. It is Glamox A90-P is decorative and tough luminaire with a design that satisfy both
suitable for mounting outdoors as well as indoors. The square Glamox A71-SQ is the requirements posed to an industrial luminaire and the high demands made by
available in two different sizes, 290x290 mm and 340x340 mm. The height is only architects and light designers when it comes to aestheticism and functionality. Based
54 mm. It has a particularly high IP rating and impact resistance class. This makes it on extensive requirements, the designers have developed a luminaire suitable for a
suitable for outdoor mounting, and for indoor mounting in areas where robustness is wide range of applications. A90-P1 is designed for applications like social areas,
needed. Suitable outdoor applications are building facades and entrance areas. receptions and canteens and A90-P2 for applications like production premises,
warehouses, entrance halls and atriums with mounting heights up to 10-12 meters.

Light source SQ290 LED 1000 lumen out Light source LED 1000 – 20.000 lumen outColour temperature
SQ340 LED 1700 lumen out 3000/4000 K, CRI Ra 80, MacAdams 3
Light source information: Ballast Fixed output (HF) or DALI dimmable.Driver lifetime up to 100
3000/4000 Kelvin, CRI 80, MacAdams 3. 000 h/10 % (max failure) at Ta 25°C
Lifetime LED: Material/colour Luminaire top in black epoxy / polyester powder coated die-
Up to 60.000h Ta25. casted aluminium and component housing in injection moulded
For precise technical information please see the data sheet on black glass reinforced polycarbonate. Cooling ribs in black
item level. (Use on right side)
anodized extruded aluminium. Reflector in anodised aluminium
Ballast Fixed output or DALI dimable AC driver (light modulation with a or opal polystyrene.
frequency of 100Hz) Optics Wide beam - (WB), medium beam - (MB) and narrow beam
Material/colour Housing in die-cast aluminium, painted in polyester powder (NB) reflector in anodised aluminium. Opal reflector in polysty-
paint in colour grey (RAL 9006) or White (RAL 9016). Diffuser rene. Reflectors have to be ordered separately.
is in impact resistant opal polycarbonate (PC).
Dimension (mm) Ø: 375 H: 406
Dimension (mm) W: 290 L: 290 H: 54 Ø: 375 H: 397
W: 340 L: 340 H: 54 Ø: 500 H: 533
Ø: 500 H: 520

For detailed information on products, see www.glamox.com 2/19
