P. 71

MODERNA2-R                                                       Modul-R100
























          The MODERNA 2 system is a family of recessed luminaries with a low glare rating,   Modul is a series of recessed luminaires that combines functionality, performance
          thereby protecting against excessive fatigue and gradual deterioration of vision.   and design. These are low glare luminaires with high efficiency and shallow recess
          It uses efficient, energy-saving LED light. The specially designed optics provide a   depth, which make them well suited for installation in ceilings with little head room.
          highly uniform illumination and exceptional working comfort. The luminaries minimalist   Lines of light in the ceiling Modul-R100 is a narrow 96mm luminaire which is offered
          design fits seamlessly in modern, austere interiors without dominating their décor. Suit-  in three different lengths. Mounting two or more luminaires end to end will create
          able for installation in a ceiling grid or plasterboard ceiling using additional mounting   lines of light in the ceiling. Modul-R100 is available with opal acrylic diffuser or
          brackets.                                                        microprismatic optics. Dimming is optional.




          Light source  LED 2700 - 5400 lumen out                          Light source  LED 1200 - 4400 lument outColour temperature3000/4000
                        Colour temperature 3000/4000 K, CRI Ra 80, MacAdams 3            K, CRI 80, MacAdams 3
          Ballast       HF or DALI.Driver life time up to 100.000 h/10 % (max failure)   Ballast  Electronic ballast (HF),or DALI.Driver life time up to 100.000
                        at Ta 25°C.                                                      h/10 % (max failure) at Ta 25°C.
          Material/colour  Body in white or black painted steel.           Material/colour  White steel body.
          Optics        Available with Microprismatic diffuser (MP) white reflector   Optics  Opal diffuser type OP or microprismatic diffuser MP.
                        (WH) and black reflector (BL).                     Dimension (mm)  W: 96   L: 1196   H: 73
          Dimension (mm)  W: 597  L: 597   H: 45                                         W: 96   L: 1196   H: 79
                        W: 595  L: 595   H: 47                                           W: 96   L: 596   H: 73
                        W: 597  L: 597   H: 47
                        W: 597  L: 597   H: 38
                        W: 597  L: 297   H: 38
                        W: 297  L: 1197   H: 38
                        W: 147  L: 1197   H: 38
                        W: 622  L: 622   H: 38











































         2/38    For detailed information on products, see www.glamox.com
