i80 i81

Glamox i80 is a family of IP66 industrial LED luminaires for surface and pendant Glamox i81 is a family of LED luminaires for surface and pendant mounting or in
mounting or in open ceilings by use of a recessing frame. Can be used in ambient open ceilings by use of a recessing frame. Delivers up to 26000 lumen out of the
temperatures (Ta) from 50°C down to -40°C. Efficient and Versatile Delivers up to luminaire. The product is designed to light industrial facilities, ware houses, produc-
34000 lumen out of the luminaire with a high CRI of 80. The product is designed tion areas and workshops. With its powerful light output, i81 is well suited for use
to light industrial facilities, ware houses, production areas, workshops and cold stor- in areas with high ceiling heights. The luminaire housing is manufactured in die-cast
ages down to Ta -40°C. Also ideal for active use in sports halls with good light and aluminium with low content of iron and copper. Epoxy/polyester powder coated
minimum glare. paint finish. Supplied with medium beam - (MB), narrow beam (NB) and extreme
narrow beam (XNB) reflector in silver coated aluminium.

Light source LED 7000 - 60 000 lumen out Light source LED 14 000 - 26 000 lumen out
Colour temperature 4000 K, CRI Ra 80, MacAdams 3 Colour temperature 4000 K, CRI Ra 80, MacAdams 3
On request: 3000 K On request: 3000 K
Ballast Fixed output (HF) and DALI dimmable (10-100%). Some vari- Ballast Fixed output (HF) and DALI dimmable (1-100%). Driver life time
ants can be dimmed down to zero (DALI-Z). Driver life time up up to 120 000 h/10 % (max failure) at Ta 25°C.
to 120 000 h/10 % (max failure) at Ta 25°C. Material/colour Luminaire housing in die-cast aluminium with low content of iron
Material/colour Luminaire housing in die-cast aluminium with low content of iron and copper (EN AB-44100). Epoxy/polyester powder coated
and copper (EN AB-44100). Epoxy/polyester powder coated paint finish. Aluminium grey (RAL 9006). Reflector in silver
paint finish. Aluminium grey (RAL 9006). Reflector in silver coated aluminium. Front cover in clear or opal polycarbonate.
coated aluminium. Silicone gasket. Screws made of acid proof steel.
Optics Medium beam - (MB), narrow beam - (NB) and extreme nar- Optics Medium beam - (MB), narrow beam (NB) and extreme narrow
row beam reflector (XNB) in silver coated aluminium. Opal film beam (XNB) reflector in silver coated aluminium. Opal (OP).
(OP). Dimension (mm) W: 380 L: 380 H: 137
Dimension (mm) W: 380 L: 780 H: 193
W: 380 L: 380 H: 137
