C90-R C91-R

Design: Hans Bleken Rud

C90-R is a family of modular LED luminaires with fully illuminated surfaces with C91-R is a modular LED luminaire for special mounting solutions. C91-R comes with
excellent design, flexibility and visual performance. With its high finish and large a fully illuminated surfaces with excellent design, flexibility and visual performance.
illuminated surface C90-R comes one with the ceiling. Excellent design C90-R is a With its high finish and large illuminated surface C91-R comes one with the ceiling.
product designed with premium light qualities with no visible luminaire frame in the Excellent design C91-R is a product designed with premium light qualities with limited
ceiling. The perfect shaped frame around the optics is made in one piece without visible luminaire frame in the ceiling. The frame around the optics is made in one
and joints and is only 12mm wide. This makes the frame invisible in the T-bar system. piece without any joints and is only 24mm wide. This makes the frame almost invis-
Perfect balance The C90-R is designed with focus on light quality. All details are ible in the T-bar system. Perfect balance The C91-R is designed with focus on light
carefully measured to achieve premium homogenous light. quality.

Light source LED 1200 - 5000 lumen out Light source LED 2200 - 5000 lumen out
Colour temperature3000/4000K, CRI Ra 80 or 90, MacAd- Colour temperature3000/4000 K, CRI Ra 80 and 90. Mac-
ams 3Tuneable white (CCT) and RGB Adams 3Tuneable white (CCT) and RGB
Ballast HF or DALI. CCT-version only DALI. Driver life time up to Ballast HF or DALI. Driver life time up to 100.000 h/10 % (max
100.000 h/10 % (max failure) at Ta 25°C. failure) at Ta 25°C.
Material/colour Body in white painted steel. Plastic frame. Material/colour Body and frame in white painted steel.
Optics Micro prismatic (MP), Opalic (OP), Circle (CI) or Opalic Drop Optics Standard with micro prismatic (MP), Opalic (OP), Circle (CI)
out (OD).Only OP/ MP on the 312x312 version. or Opalic Drop out (OD). Can also be delivered with glass in
Dimension (mm) W: 597 L: 597 H: 71 front of theopalic or micro prismatic optic(MP/GL, OP/GL) or
W: 297 L: 1197 H: 71 polycarbonate (PC). IK10 with diffusor in polycarbonate (PC).
W: 597 L: 597 H: 149 Dimension (mm) W: 597 L: 597 H: 71
W: 622 L: 622 H: 71 W: 297 L: 1197 H: 71
W: 309 L: 309 H: 71
