Wave LED ESD Wave LED UV

Design: Aleksander Borgenhov Design: Aleksander Borgenhov

Wave LED ESD is especially made for the electronics industry where electrostatic Wave LED is a magnifier for industrial applications. It is now available with integrat-
discharges can prove fatal for electronic components. It is designed to drain away ed UV-A light sources. The UV versions are primarily designed for the inspection of
static charges as they occur in a controlled manner. Wave LED ESD offers shadow- conformal coatings. UV tracer conformal coatings observed under the Wave LED UV
free magnification with light coming from both sides, as well as three-dimensional light source glow a dark purple colour allowing for easy identification of uncoated
magnification with light coming from the left or right. The 3D-feature is especially wel- areas. Experienced users can also see the volume of coating at different locations
come when working with circuit boards and similar delicate objects. Colour: Black across a circuit board's " surface. The 365nm UV-A light sources are also ideal for
Maximum flexibility and precision The flexibility of the joint between lamp head and the inspection of welds, solder joints and other areas of stress contamination.
arm makes exact positioning easy.

Light source Supplied with 2 x integrated LED modules. Correlated colour Light source Two dimmable 365nm UV-A LED modules. Step dimming:
temperature (CCT) is 4000°K. Colour rendition index (CRI) is 0-50-100%.
80.The LED modules are dimmable, 0–50–100%. Material/colour Steel arm and die-cast aluminum shade. Fully-enclosed neck
Material/colour Steel arm, shade in aluminium. Colour: Black. design. Colour: Black.
Optics Standard with 3.5 or 5 diopter crown glass lens. Lens dimen- Optics Standard with 3.5 or 5 diopter rectangular crown glass lens.
sions are 175 x 108 mm.For additional magnification a sec- Lens dimensions are 175 x 108 mm. For additional magnifica-
ondary lens, 4D, 6D or 10Dcan be attached to the magnifier. tion, a secondary 4-, 6- or 10-diopter lens can be attached to
Dimension (mm) W: 227 L: 224 H: 70 the primary lens.
