RACER RACER MINI

RACER is a slim LED floodlight for street and urban lighting. For mounting on pole RACER MINI is a slim LED floodlight for street and urban lighting. For mounting on
with top diameter of 48-60 mm. RACER is manufactured with luminaire housing in pole with top diameter of 48-60 mm. RACER MINI is manufactured with luminaire
die-cast aluminium with polyester powder coated paint finish. The optical system housing in die-cast aluminium with polyester powder coated paint finish. The optical
consists of lens panels. Supplied with tempered safety glass cover. The luminaire has system consists of lens panels. Supplied with tempered safety glass cover. The lumi-
silicone gasket and all screws are in stainless steel. naire has silicone gasket and all screws are in stainless steel.

Light source LED 13 500 - 25 000 lumen out. Light source LED 2600 - 17 000 lumen out
Colour temperature 4000/5700 K, CRI Ra 70, MacAdams 3 Colour temperature 3000/4000/5700 K, CRI Ra 70, Mac-
Ballast Fixed output (HF) and DALI dimmable. Adams 3
Material/colour Body in die-cast aluminium with grey (RAL 7042) polyester Ballast Fixed output (HF). DALI dimmable on request.
powder coated paint finish. The optical system consists of lens Material/colour Body in die-cast aluminium with grey (RAL 7042) polyester
panels. Supplied with tempered safety glass cover. The lumi- powder coated paint finish. The optical system consists of lens
naire has silicone gasket and all screws are in stainless steel. panels. Supplied with tempered safety glass cover. The lumi-
Optics Medium beam asymmetrical optic (MBA). naire has silicone gasket and all screws are in stainless steel.
Dimension (mm) W: 985 L: 345 H: 115 Optics Wide beam optic for street and pathway lighting (WBA),
W: 345 L: 985 H: 115 medium beam asymmetrical - (MBA), Asymmetric left - (ASY-L)
and asymmetric right optic (ASY-R).
Dimension (mm) W: 345 L: 826 H: 107
W: 826 L: 345 H: 107
W: 825 L: 335 H: 100
W: 826 L: 345 H: 100
